Technical Specification

• Ambient Temperature (℃) -30~46
• Max Altitude (m) 3000
• Driving Range (km) ≥400
• Average Unit Pressure of Ground (kPa) ≤85
• Max Transverse Angle (%) ≥ 40
• Min Turning Diameter () pivot steering
• Max Width of Ditch ≥1000
• Max Height of Surmountable Obstacle (mm) ≥300
• Max Speed (km/h) ≥60
• Max Climbing (%) ≥60
• Traction Weight (kg) ≤1000
• Load Weight (kg) ≤1100
• Weight of Complete Vehicle (kg) ≤1750
• Minimal Ground Clearance (mm) ≥ 250
• Departure Angle (°) ≥ 45
• Approach Angle (°) ≥ 45
• Total Height (mm) ≤1500（1800, including the roll bar）
• Total Width (mm) ≤1900
• Total Length (mm) ≤3900
